Murrelektronik Murrelektronik 7000-46041-8021000
Cube67
Male straight – female straight
M12 – M12, 6-pole
Shielded
A-coded
Hybrid cable
Plastic housings with good resistance against chemicals and oils.
| Material short text | MSBL0-A-6p2_802_10.0-ZE |
|---|---|
| Cable length | 10,00 m |
| Family construction form | M12 |
|---|---|
| No. of poles | 6 |
| Coding | A |
| Gender | male |
| Mounting method | inserted, screwed |
| Threaded hole | M12 x 1 |
| Tightening torque | 0,6 Nm |
| Width across flats | SW13 |
| Cable outlet | straight |
| Material | PUR |
| Material contact | Copper alloy |
| Coating contact | gold plated |
| Degree of protection (EN IEC 60529) | IP65, IP66K, IP67 |
| Family construction form | M12 |
|---|---|
| No. of poles | 6 |
| Coding | A |
| Gender | female |
| Mounting method | inserted, screwed |
| Threaded hole | M12 x 1 |
| Tightening torque | 0,6 Nm |
| Width across flats | SW13 |
| Cable outlet | straight |
| Material | PUR |
| Material contact | Copper alloy |
| Coating contact | gold plated |
| Degree of protection (EN IEC 60529) | IP65, IP66K, IP67 |
| Operating voltage AC max. | 30 V |
|---|---|
| Operating voltage DC max. | 30 V |
| Current operating per contact max. | 4 A |
| Operating voltage AC (UL-listed) | 30 V |
| Operating voltage DC (UL-listed) | 30 V |
| Status indication LED | No |
|---|
| Degree of protection (EN IEC 60529) | IP67, IP65 |
|---|---|
| Additional condition protection degree | inserted, screwed |
| Pollution Degree | 3 |
| Rated surge voltage | 0,8 kV |
| Material group (IEC 60664-1) | I |
| Locking material | Zinc die-casting |
|---|---|
| Coating locking | Nickeled |
| Material gasket | FKM |
