Max Motion JMQP-46S | Pump - JM Motor 25HP, 3600RPM, 208-230/460V, ...
Forces Inc Max Motion JMQP-46S | Pump - JM Motor 25HP, 3600RPM, 208-230/460V, Frame 256JM, TEFC
Product Details : Max Motion JMQP-46S | Pump - JM Motor 25HP, 3600RPM, 208-230/460V, Frame 256JM, TEFC
- Part No: JMQP-46S
- Product Type: Pump - JM Motor
- Brand: Max Motion
- Frame: 256JM
- Horsepower (HP): 25
- RPM: 2 pôles-2500 to 3600
- Voltage: 208-230/460 (3 PH)
- Phase: 3
- Enclosure: TEFC
- Material(s): Cast Iron
-
Details:
• MG-1 Design B and MG-1 Part 31
• Meets or exceeds NEMA Premium Efficiencies
• Factory Certified Division 2 Class I Groups A, B, C, D Class II Groups F&G.
• Meets Temperature Code T2B.
• At 60Hz : 208-230/416-460v Dual Rated for 50Hz : 190/380-415v
• IP55 enclosure.
• Inverter Duty 10:1 Constant Torque, 20:1 Variable Torque 1.0 SF.
• Meets MG1 parts 31.4.4.2
• 1.25 Service Factor 1-50HP
• Class F Insulation
• C and D Flanges are available
• F1 Standard Assembly, Reversible to F2 Assembly
• CSAus & CE Certified
• Three Years Warranty
For any information about products, please contact us.
*Photos for reference purposes only.
