NOARK® Motor-Circuit Protector 50A Frame M1, N IC Class 3P | M1MN50T3L
NOARK® Motor-Circuit Protector 50A Frame M1, N IC Class 3P | M1MN50T3L - 50A / 65kA @ 480Vac / N (High Interrupting Capacity) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Bulk/Custom/Contract Purchase Options
Bulk/Custom/Contract Purchase Options
Please contact us at sales@infinitesupplyandservices.com to discover more about Bulk/Custom/Contract Purchase Options, with a dedicated team member ready to cater to your needs swiftly.
Delivery and Shipping
Delivery and Shipping
Our fulfillment team is working non-stop to fulfill your requirements. Contact us at sales@infinitesupplyandservices.com for expedited options
NOARK® Motor-Circuit Protector 50A Frame M1, N IC Class 3P | M1MN50T3L
Forces Inc NOARK® Motor-Circuit Protector 50A Frame M1, N IC Class 3P | M1MN50T3L
Product Details : NOARK® Motor-Circuit Protector 50A Frame M1, N IC Class 3P | M1MN50T3L
- Part No: M1MN50T3L
- Product Type: NOARK® Motor-Circuit Protector
- Brand: NOARK®
- Series: M1M
- Frame Size: Frame M1
- IC Class: N (High Interrupting Capacity)
- Interrupting Capacity: 65kA @ 480Vac
- Rated Current (Amps): 50A
- No. Of Poles: 3
- Connection Type: Lug Line/Load Side
- Cam Setting: A, B, C, D, E, F, G
- Full Load Current at Cam Setting A: 19.2 to 22.9 A
- Full Load Current at Cam Setting B: 23.0 to 26.8 A
- Full Load Current at Cam Setting C: 26.9 to 30.6 A
- Full Load Current at Cam Setting D: 30.7 to 34.5 A
- Full Load Current at Cam Setting E: 34.6 to 38.3 A
- Full Load Current at Cam Setting F: 38.4 to 42.1 A
- Full Load Current at Cam Setting G: 42.2 to 43.5 A
- (MCP) Trip Setting at Cam Setting A: 250
- (MCP) Trip Setting at Cam Setting B: 300
- (MCP) Trip Setting at Cam Setting C: 350
- (MCP) Trip Setting at Cam Setting D: 400
- (MCP) Trip Setting at Cam Setting E: 450
- (MCP) Trip Setting at Cam Setting F: 500
- (MCP) Trip Setting at Cam Setting G: 550
For any information about products, please contact us.
*Photos for reference purposes only.
