Leeson X305 | HVAC Motor 1/6HP, 1800RPM, 115V, Frame 48Z, TEAO
Forces Inc Leeson X305 | HVAC Motor 1/6HP, 1800RPM, 115V, Frame 48Z, TEAO
• Dimension Print Available Here
Product Details : Leeson X305 | HVAC Motor 1/6HP, 1800RPM, 115V, Frame 48Z, TEAO
- Part No: X305
- Product Type: HVAC Motor
- Category: Permanent Split Capacitor
- Brand: Leeson/Marathon
- Frame: 48Z
- Enclosure: TEAO
- Horsepower (HP): 1/6
- Poles: 4
- RPM: 1400 to 1800
- Voltage: 115V
- Phase: 1
- Number Of Speeds: 1
- Frequency (Hz): 60
- Amps: 2
-
Features:
• Unit Heater Fan, PSC, TEAO Motors
• Resilient Base Motors
• Totally enclosed
• Direct drive, air over
• Ball bearings
• Horizontal or vertical mount
• Weather resistant reversing plug
• BX connector mounted in frame
• 1” extended thru-bolts
• Automatic reset thermal protection
• UL recognized and CSA certified
• Capacitor included
• 48Y frame has non-standard BA dimension
• Model 048A17T2001
For any information about products, please contact us.
*Photos for reference purposes only.
