Product Details : Leeson FX01BK002 | FLEX-IN-1™ General Purpose Motor 1HP, 3600RPM, 208-230/460V, Frame 56C, TEFC
- Part No: FX01BK002
- Product Type: FLEX-IN-1™ General Purpose Motor
- Brand: Leeson/Marathon
- Frame: 56C
- Enclosure: TEFC
- Horsepower (HP): 1
- Poles: 2
- RPM: 2500 to 3600
- Voltage: 208-230/460V
- Phase: 3
- Number Of Speeds: 1
- Frequency (Hz): 50-60
- Amps: 3.3/1.5
-
Features:
• One FLEX-IN-1™ motor replaces 18 general purpose motors
• The patented FLEX-IN-1 motor is easily configured into three mounting styles: F1, F2 & F3
• Out-of-the-box motor with provisions for multiple kits*** - Adding SGR (shaft grounding ring) kit; Adding a brake kit; Adding a drip cover (ODP); Adding lint guard (TEFC).
• Inverter duty capable - 10:1 CT for TEFC - 2:1 CT for DP
• Combination mounting holes in base: 56/143 – Shorter base motor option and 56/56H/143/145 – Longer base motor option
• *** Kits sold separately. Light assembly required.
